Cold Chain Temperature Monitoring Devices

CASE SPECIFICATIONS

Case Material:

UL 94-V0 flame retardant plastic

Dimensions:

96 x 58 x 21 mm

Weight:

TT-7100 159 g (5.6 oz)

Mounting:

3M Adhesive, Cable Tie

IP Rating:

IP67

SENSORS

Condition Sensors:

Temperature, l ight, h umidity, s hock, t ilt, motion

TEMPERATURE ACCURACY

±0.5°C

Drift less than 0.01°C per year

Certificate of Calibration

(3-Point, ISO 17025)

CERTIFICATIONS

Fully validated and GxP compliant

FDA 21 CFR Part 11 and EU Annex 11

SOC 2 Type 2 and ISO/IEC 27001

Flight safe, IATA, FAA, EASA

FCC, IC, NOM, CE, UKCA, RCM, SRRC, Giteki, KC*, NCC*, ETA*, MIC*

*In progress

OPERATING TEMPERATURE

-30°C to 60°C (-22°F to 140°F)

Screen visible between -20°C and 60°C

DISPLAY

High Contrast, ePaper 2.66 in (68 mm)

Clear view on alarms, start/stop & data upload status

TRANSPORT

Road, air, ocean, rail

GLOBAL COVERAGE

95%

With 400+ networks

LOCATION TECHNOLOGY

Cellular, GPS, WiFi

BATTERY

Rechargeable

NiMH (Non-Lithium)

LOCATION ACCURACY

Advanced GPS: 10 m (33 feet)

WiFi Geolocation: 50 m (<150 feet)

Cellular Triangulation: 500 m (0.3 miles)

TRANSMISSION INTERVAL

5 min to 12 hours, programmable
