GLOBAL CELLULAR ACTIVITY

Transmission Type:
LTE-M Global Bands: B1/B2/B3/B4/B5/B8 B12/B18/B19/B20/B25/B16/B28/B66/B85 EGPRS (2G) Bands: 850/900/1800/1900

Communication Interval:
5 – 720 min, programmable, event-driven immediate communication for excursion events

LOCATION

Location Method:
Cellular & WiFi Geolocation

Location Accuracy:
WiFi Geolocation: 50 m (<150 feet)
Cellular Triangulation: 500 m (0.3 miles)

OPERATING RANGE

TT-8000
-20°C to 60°C (-4°F to 140°F)

TT-8100
-20°C to 60°C (-4°F to 140°F)

DISPLAY INDICATOR

LED lights indicate Start and Status

SENSORS

Condition Sensors:
Temperature, Light, Motion

Temperature Accuracy:
±0.5°C (±0.9°F)
Drift less than 0.01°C (0.02°F) per year

Measurement Interval:
5 – 720 min, programmable

Measurement Capacity:
Up to 25,000 records

BATTERY

Solo Lite Lithium Tracker (TT-8000)

Rechargeable Lithium-Ion battery
(3.7 V, 2600 mAh / 9.62 Wh capacity)

Active life: 60+ days (60 min reporting interval)

Shelf life: 180 days Solo Lite

Non-Lithium Tracker (TT-8100)

Rechargeable Nickel-Metal Hydride battery
(2200 mAh, 3.6 V)

Active life: 30+ days (60 min reporting interval)

Shelf life: 12 months

CASE SPECIFICATIONS

Case Material:
UL 94-V0 flame-retardant plastic

Dimensions:
TT-8000 & TT-8100
92 x 62 x 22.5 mm (3.6 x 2.4 x 0.9 in)

Weight:
TT-8000
90 g (3.2 oz) TT-8100
140 g (4.9 oz)

IP Rating:
IP65

Mounting:
3M Adhesive, Cable Zip Tie

CERTIFICATIONS

FCC, IC, CE, UKCA, UN38.3, RTCA DO-160G, flight compliant
